16ch 4K NVR with 8 x PoE & P2P Remote View
Introducing our revolutionary 16-channel 4K NVR with 8 x PoE & P2P Remote View. This state-of-the-art security system is NDAA compliant, ensuring the highest standards of safety and privacy. With stunning 4K resolution, you’ll experience crystal clear, high-definition video that captures every detail.
What sets this system apart is its advanced motion detection feature. It provides real-time alerts, sending push notifications directly to your device upon detecting any movement. This means you can stay informed and react quickly to any potential security threats.
But that’s not all! Our NVR system also offers a remote view feature, allowing you to monitor your premises from anywhere, anytime. Whether you’re at home, at the office, or on the go, you can easily access your security feeds via your smartphone or computer.
Additionally, the system comes with a 2-way audio feature, allowing you to communicate directly through the camera. This can be incredibly useful in various situations, from deterring potential intruders to communicating with delivery personnel.
The system is also equipped with Onvif compatibility, making it flexible and adaptable to work with most cameras. Plus, with PoE (Power over Ethernet), you can enjoy simplified installation and reduced cabling.
The 16ch 4K NVR with 8 x PoE & P2P Remote View is a comprehensive security solution that combines high-quality video, proactive alerts, remote access, and seamless compatibility for ultimate peace of mind. Secure your premises today with our advanced, user-friendly system.
NVR Features
- NDAA Compliant
- 4K resolution
- Motion detection
- Push notifications on motion
- Remote view
- 2 way audio
- Audio
- Onvif for compatibility with most cameras
- PoE
- IP
- 3 year warranty
Works with:
OzSpy IP Cameras
HikVision Cameras
Dahua Cameras
Onvif Cameras
Specifications
System
Main Processor ARM Cortex A7 Processor
Operating System Embedded LINUX
Video
Input 9CH(3840*2160,2592×1944, 2048×1536, 1920×1080, 1280×960, 1280×720, etc)
Output 1 VGA, 1 HD
Audio
Input 1 Port RCA
Output 1 Port RCA(Linear, 1kΩ)
Audio Bit Rate 64kbps
Audio Compression standard G711u, G711a, ADPCM_DVI4
Intercom support (two-way)
Alarm
Sensor Input 4
Output 1
Motion Detection 9 Channel, MD Zones: 396 (22 × 18)
Trigger Events Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
Display
HD Output1 1024×768/60Hz，1280×720/60Hz，1280×1024/60Hz，1920×1080/60Hz，4K(3840×2160)/30Hz
HD Output2 /
VGA Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Display Split 9CHxD1/8CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k
Digital Zoom YES
OSD Camera Title, Time, Recording, Motion Detection, Event Alarm
Recording
Video Compression H265/H264/H265+/H264+
Resolution 4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),960P(1280×960),720P(1280×720),D1 (720×576/720×480)
Record Rate PAL :4K@8x25fps,5MP@9×25fp,4MP@9x25fp,3MP@9×25fp,1080P@9×25fp, 960P@9×25fp,720P@9×25fp, D1@9×25fp
NTSC: 4K@8x30fps,5MP@9×30fp,4MP@9×30fp,3MP@9×30fp,1080P@9×30fp, 960P@9×30fp, 720P@9×30fp, D1@9×30fp
Record Mode ManualTimerMotion Detection AlarmMotion and AlarmSmart Alarm
Playback & Backup
Local Sync Playback 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps
Decode Capability 4CH 1080P(1920×1080)@30fps
Remote Sync Playback YES
Search Mode ALL, Channel, Manual, Time, Date, Motion Detection,Event Alarm,Tag search
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow Play, Full Screen, Frame Play ,Frame Rewind, Digital Zoom,tag,clip
Backup Mode USB Device/Network
Network
Interface 1xRJ45 10M/100MAdaptive Ethernet Interface
Incoming Bandwidth 80MB
Network Functions TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE
Onvif onvif S,onvif T
Web Browser IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS Software Support Windows 7/ Windows 8/Windows 10/MAC OS
Cloud Support Yes
Smart Phone iPhone, iPad, Android, Android Pad
POE 4 x Independent 100Mbps POE Network Interfaces(Output PowerAT mode 30W, AF mode 15W per Interface), 45/78 line order, Total Power Output≧50W, Support Plug and Play, Support network cable extended mode Max. 200M
WIFI UI /
Storage
Interface Type 1 SATA Hard Disk Interface (3.5″ SATA)
Capacity Up to 8TB capacity
eSATA /
General
Language UI Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese,Janpanese
USB Interface 2 USB 2.0 Interfaces
RS485 /
Power Supply DC52V∕1250mA
Working Environment -10~55℃/10~90%
Dimension(W×D×H) 260*215*43(mm)
Weight 2kg(without HDD)
NVR Recorder Manual
➲Download Manual Here
